• Repair Section
  • Brakes
  • Body
  • Clutch Transmission
  • Cooling System
  • Driveshaft
  • Electrical, Chassis
  • Electrical, Engine
  • Emission Controls
  • Engine Repair
  • Exploded Views
  • Fuel System
  • Rear Axle
  • Steering
  • Suspension
  • Ventilation
• Technical Specifications
  • Brake Cylinder
  • Coil Spring Specification
  • Cooling System
  • Driveshaft Assembly
  • Frame Charts
  • Fuel Tank
  • Leaf Spring Specification
  • Rear Axle Specifications
  • Speedometer Cable
  • Sway Bar
  • Steering Box and Pitman Arm
  • Throttle Cable
  • Wheel Alignment
  • Wheel Specifications
  • General Engine Specifications
  • Tuneup Specifications
• Wiring Diagrams
  • 1970 Maverick
  • 1971 Maverick
  • 1972 Maverick
  • 1973 Maverick
  • 1974 Maverick
  • 1975 Maverick
  • 1976 Maverick
  • 1977 Maverick
  • 1971 Comet
  • 1972 Comet
  • 1973 Comet
  • 1974 Comet
  • 1975 Comet
  • 1976 Comet
  • 1977 Comet
• Vacuum Diagrams
  • 1970-1972
  • 1973
  • 1974 without AC
  • 1974 with AC
  • 1975 without AC
  • 1975 with AC
  • 1976 without AC
  • 1976 with AC
  • 1977 without AC
  • 1977 with AC
• Maverick Differences
• Used Parts For Sale
